DEKEMA AUSTROMAT™ 674

- new device -

• High temperature furnace for sintering up to 1530°C
• complete with firing table for sintering in one plane up to 100 mm Ø
• Calibration set, tweezers
• Optional: temperature upgrade to 1,560°C, software package
• Sintering in two levels

The AUSTROMAT™ 674 is equipped with three silicon carbide heating elements that ensure sintering temperatures of up to 1,530 °C. These heating elements are characterized by their particular robustness and longevity and do not discolor the sintered material. The combustion chamber is closed by the lift, which moves without vibration. With this oven we also use the proven AutoDry system to create high temperature gradients during the heating and cooling phases. This safely enables the shortest possible sintering times through controlled lift movement. Each sintering platform has space for around forty units with a diameter of up to 100 mm, stackable with a second level available as an accessory. Sintering programs are either pre-programmed at the factory, via USB stick or optionally loaded directly from the Internet from the DEKEMA database. Or via one-button operation by adding a QR code reader. It is operated via the colored 7.5″ touch control unit, which also provides information about the oven status.

Features:

• Dimensions (H x W x D): 780 x 383 x 343 mm3
• Weight: 24kg
• Voltage: 230V / 50 to 60 Hz
• Maximum power consumption: 2 kW
• Tmax: 1,530°C
• Touch screen screen: 7.5” color
• Programming languages: Classic
• DEKEMA Autodry
• Program continuation after power failure
• Housing: aluminum, anodized
• Customization of corporate design, optional
• Radiator SiC: DEKEMA-specific, high-purity heating elements made of SiC (silicon carbide), sintering at high temperatures, no discoloration
• Fiber insulation multi-compound: multi-layer insulation system for sintering at high temperatures
• Fiber insulation table multi-compound: for sintering at high temperatures
• Sintering accessories for sintering in one plane
• Sintering accessories for sintering in the second level, optional
• Micro-Pearls: safe and distortion-free storage of sintered material, optional
• Sinter plate micro pearls
• QR code reader, optional
• USB interface: transferring burning programs (dds)/transferring image data (jpeg)/storing QM files (dfl)
